KOMG-CT-EX
(Compact & Explosion-proof Type)

Product Discription

Compact Type Electromagnetic Flow Meter

The KOMG-CT-EX is a compact, high-precision electromagnetic flow meter designed to measure the flow of conductive liquids based on Faraday’s law of electromagnetic induction.
With an integrated sensor and converter, it offers excellent space efficiency for confined installations, while its non-moving part design ensures minimal pressure loss, high durability, and long-term operational stability.
Ideal for water, wastewater, chemicals, pharmaceuticals, food, and slurry, it provides accurate flow monitoring with ±0.5% accuracy (optional ±0.2%) and rapid response performance.

✔ Non-wearing structure ensures extended service life
✔ Integrated sensor and transmitter for compact and easy installation
✔ High accuracy: ±0.5% (Option: ±0.2%)
✔ LCD display for real-time flow rate, total volume, and diagnostic codes
✔ Wide selection of liner materials: PFA, PTFE, hard rubber, etc.
✔ Compatible with all conductive fluids: water, wastewater, chemicals, food, slurry
✔ IP65-rated waterproof housing for outdoor installation
✔ Multiple output signals supported: 4–20mA, Pulse, RS485 (Modbus RTU)
