KOMG-CW-EX
(Compact & Explosion-proof Type)

Product Discription

Compact Type Electromagnetic Flow Meter

The KOMG-CW-EX is a compact, integrated electromagnetic flow meter that operates on Faraday’s law of electromagnetic induction to measure the flow of conductive liquids with high precision.
Its all-in-one sensor and transmitter design allows for efficient installation in limited spaces, while the non-moving part construction ensures minimal pressure loss, long-term durability, and reliable performance in harsh industrial environments.
Widely used in water treatment, wastewater, chemical plants, pharmaceuticals, food processing, and slurry applications, this model delivers ±0.5% accuracy (optional ±0.2%) and fast response for optimal flow monitoring.
Processing, and slurry applications, this model delivers ±0.5% accuracy (optional ±0.2%) and fast response for optimal flow monitoring.

✔ Non-wearing design for long-lasting performance
✔ Compact all-in-one structure ideal for confined installation spaces
✔ High accuracy: ±0.5% (Option: ±0.2%)
✔ Real-time flow, totalizer, and diagnostics via LCD display
✔ Multiple liner materials available: PFA, PTFE, hard rubber, etc.
✔ Applicable to all conductive fluids: water, wastewater, chemicals, food, slurry
✔ IP65-rated enclosure for outdoor installation
✔ Standard output signals: 4–20mA, Pulse, RS485 (Modbus RTU)
