KOMG-CS-EX
(Compact & Explosion-proof Type)

Product Discription

Compact Type Electromagnetic Flow Meter

The KOMG-CS-EX is a compact and integrated electromagnetic flow meter designed to measure the flow of conductive liquids using Faraday’s law of electromagnetic induction.
Its sensor and converter are combined into a single unit, allowing for efficient installation in tight spaces. With no moving parts, it offers minimal pressure loss, exceptional durability, and long-term stability in various industrial settings.
The KOMG-CS-EX is widely used in applications such as water supply, wastewater treatment, chemical processing, pharmaceuticals, food and beverage, and slurry handling, delivering ±0.5% measurement accuracy (optional ±0.2%) with fast and reliable response.

✔ Non-wearing structure for semi-permanent service life
✔ Integrated sensor and transmitter for compact installation
✔ High accuracy: ±0.5% (Option: ±0.2%)
✔ Real-time monitoring of flow, totalizer, and status codes via LCD display
✔ Customizable liner/electrode materials: PFA, PTFE, hard rubber, etc.
✔ Applicable to conductive fluids: water, wastewater, chemicals, food, slurry
✔ IP65-rated waterproof design for outdoor use
✔ Standard output options: 4–20mA, Pulse, RS485 (Modbus RTU)
