KMFA-N-1
(Vertical Installation · Threaded Connection Type)

Product Discription

Vertical Installation · Threaded Connection Type

The KMFA-N-1 Series is a metal tube variable area flow meter designed for vertical pipe installations, featuring a PT/NPT threaded connection for easy installation without flanges. This compact structure is ideal for narrow spaces and small-diameter pipelines, providing reliable and precise flow measurement for liquids and gases in various process applications.

The flow rate can be visually confirmed by observing the float position, while optional features such as 4–20mA analog output and reed switch alarm contact enable easy integration with control and monitoring systems. With a lightweight design, simple pipe connection, and ±1.5% F.S. accuracy, the KMFA-N-1 is a practical solution for small to mid-scale flow applications.

✔ Threaded connection design (PT/NPT) for vertical pipe installation
✔ Compact structure suitable for narrow spaces and small pipe diameters
✔ Compatible with various fluids such as liquids, gases, and steam
✔ ±1.5% F.S. accuracy and 10:1 turndown ratio
✔ IP65-rated dust and water protection for high-temperature and pressure environments
✔ Optional 4–20mA output and reed switch alarm contact
✔ Wetted materials available in STS304, STS316, and others
